Bags Filling & Stitching Machine Up To 50Kg (PSL50)

Bags Filling & Stitching Machine | Semi-Automatic Weighing System up to 50Kg – PSL50

A semi-automatic filling and stitching machine built for heavy-duty packaging of powders, grains, legumes, nuts, pet food, and more. Using a 4-head weighing system, it handles 5–50 kg bags at a speed of 1–2 bags per minute, with a capacity of 3–6 tons.

Product weight is set via a touchscreen programmable logic controller, then released by foot pedal into bags conveyed to a sewing or sealing unit. Built with 304 stainless steel, it includes a custom conveyor, tank capacity of 800–1000 kg, and works with all thermal films except PE. Supported by premium components ensures efficiency, reliability, and precision for industrial-scale packaging needs.

Technical Specifications

Packable Products	All Kinds of Legumes Rice Sugar Snacks Nuts Pasta Dry Fruits Detergent Powder Granular Tea Cornflakes Coffee Bean Powder Food Granulated Beverage Pet Food Candy Powder Drink
Filling Type	Weighing (4 Multi-Heads)
Packaging System	Sewing or Sealing
Packaging Range	5-50 Kg.
Working System	Semi-Automatic
Packaging Speed	1-2 Sacks/Bags per Minute
Packaging Capacity	3-6 Tons
Power Requirement	10 Kw
Structure	304 Stainless Steel

Product Details

Filling Section
The desired weight is set via the touchscreen control panel. Then, a foot pedal is used to command the release of materials downwards. After that, the bag is conveyed on a conveyor belt to the sewing machine or sealing machine.

Packaging Section
Working System: Mechanical – Servo Motor – Pneumatic (customized)
Bag Shape: Customized
Machine works on all types of thermal rollers except Polyethylene/PE

Electrical Control
Multi-language PLC contains all the functions of the machine

Tank Capacity
800 kg / 1000 kg according to the material

Electric Parts
Schneider – LS – Fuji Electric – Festo

Inverter
Fuji Electric – Japan

Motors
Volt – Turkey
